Coolerguys Thermostat Controlled Single 120mm USB Fan Kit

Coolerguys Thermostat Controlled Single 120mm USB Fan Kit

USB powered Thermostat controlled for easy setup and operation. Quiet 120mm fan: turns on at 88 degrees F and off at 81 degrees F Comes with screws, bolts and mounting bracket, everything you need to setup and install the unit Can be used for intake or exhaust
This is a complete finished unit ready to install and quietly cool your cabinet or multimedia center. All you need to power is a standard USB port. This deluxe unit is fitted with a very quiet 1200 RPM fan coupled with our new USB Thermostat Fan Controller. It is programmed for simplicity to turn on at 88 degrees and off at 81 degrees F.

Coolerguys Preset Thermostat Fan Controller. The controller comes with a 24" temperature probe that allows for easy placement.

Built for mounting on any side of a cabinet where room permits by cutting a hole approximately 3/4" smaller on all sides of the outside bracket. Insert completed cooler assembly in hole and attach to cabinet with appropriate screws. Fans can be set to blow into or out of the cabinet depending on your needs.

Cooling Unit includes the following:

(1) Coolerguys 120 x 25mm Ultra Quiet Dual Ball Bearing Fan / 5V
(1) Black Acrylic Fan bracket (8.25" x 6.25" x .125")
(1) Coolerguys USB Preset Thermal Fan Controller
(1) Black 120mm fan grills
(1) Black 120mm Mesh Grill with Honeycomb 6mm holes
(8) Fan Case Screws Black
(4) 1/2" black Cabinet screw(s) to attach cabinet.
(1) Nylon Multi-Purpose 4" Tie Black (1 pk)


Front plate Dimensions: 8.25" x 6.25” (210 x 159mm)
Cabinet Cut-out Size: 7.4” x 5.12” (188 x 130mm) (measure and check twice)
*Fan Specs:
Dimensions: 120x120x25mm
Bearing: Dual Ball
1200 RPM
Operation Voltage: 3.5V-5.5VDC
Input current: 0.30 Amp Max
Operation temperature: -10 to +65 C
Storage temperature: -40 to +70 C
RPM: 1200 +/- 10%
CFM: 46
dB: 20
