uxcell SPST On-Off 2 Terminal 2 Position Boat Rocker Switch Black AC 20A/125V 22A/250V

uxcell SPST On-Off 2 Terminal 2 Position Boat Rocker Switch Black AC 20A/125V 22A/250V

【Wide Application】This mini rocker switch is widely used for various kinds of household appliances and DIY power control ,such as , boat, truck , pannel DIY control, lights, water dispenser, genertor, coffee pot, speaker,TV, conmutador Vacuum Cleaner and breadboard DIY power control. 【DIY As You Like】 AC 20A/125V 22A/250V,(DPST) Contact Type, 4 Terminals.Snap-in mounting. Please pay attention to the voltage before ordering to make sure the rocker switch can work successfully in your area. 【Product Basic Parameters】Marked on the rocker: I/O (on/off) for precise indications. 【Attention】Select the appropriate soldering iron to speed up the soldering. It is recommended to use 20W soldering iron to complete the soldering within 3 seconds. The flux must be in proper amount. When soldering, try to turn the switch pin down. 【Parcel contains】1 x Rocker Switch . Easy to install and durable.With our strict quality control system, we test each item and ensure in good condition before we ship. Specification:

Product Name:Rocker Switch
Pole and Throw:SPST
Terminal Quantity:2
Position:On-Off
Rated Voltage:AC 20A/125V 22A/250V(for resistive load only)
Overall Size:32 x 14 x 37mm (L*W*H)
Mounting Size:30 x 10mm (L*W)
Color:Black
Material:Plastic, Metal
Package Content:1 x Rocker Switch

AC 250V Current rerating for different loads
Inductive Load: 7.7A
Lamp Load: 3.96A
Motor Load: 4.4A
Capactive Load: 3.96A

AC125V Current rerating for different loads
Inductive Load: 7A
Lamp Load: 3.6A
Motor Load: 4A
Capactive Load: 3.6A

Very Important Notice:Ratings on the switch label are only for Purely Resistive AC load, for other types of loads please refer to the ratings above.DC load Current ratings are much lower than AC load,if you need to use this switch with more than 0.5A DC load,contact us for compatibility at first.
