Assorts Rotary Table 4"/100 mm with 4''Round Vice + T nuts- Milling Metalworking Engineering Tools

Assorts Rotary Table 4"/100 mm with 4''Round Vice + T nuts- Milling Metalworking Engineering Tools

Best Combo Of 4" /100 Rotary Table With 4'' A Caste Iron Round Vice- For Milling Machines Rotary Table's Gear Ratio - 36:1, Which Basically Means That The 1 Rotation Of The Handle Shall Rotate The Table By 10 Degrees. Rotary Table's Base Dimensions: 4. 1/8" X 3. 1/4" 4 T-slots: 5/16" Buy Genuine Brand- Assorts Product !! - A +40 Years Old Manufacturing Company Description: Specifications Of 4" (100 Mm) Rotary Table:- Designed For Smaller Milling Machines. Table Diameter 100 Mm Table Is Graduated 360 Degrees. Worm Gear Ratio -1:36, Which Means That The 1 Handle Rotation Shall Turn The Table By 10 Degrees. Center Height In Vertical Position: 2-1/16" (50 Mm Approx) Hand Wheel Is Graduated In Divisions Of 10 Min & Can Be Set To Zero. Can Be Mounted Both In Horizontal & Vertical Position. ​ Specifications Of Round Vice:- Made Of Grade Close Grain Caste Iron. Designed To Fit Our 4" (100 Mm) Rotary Tables Perfectly. The Moving Jaw Has V-grooves To Hold Round Objects. Again These Vices Are Drilled In A Manner That These Can Fit To A 3 As Well 4 Slot Table. The Drills Are Counter Bored To Ensure That The Fixing Screws Sets Perfectly Ensure Perfect Movement. Diameter Of Base - 105 Mm Jaw Width - 77 Mm Jaw Depth - 21 Mm Jaw Opening - 40 Mm Height Of The Vice Alone - 32 Mm
