uxcell SCS8UU Linear Ball Bearing Slide Block Units, 8mm Bore Dia (Pack of 4)

uxcell SCS8UU Linear Ball Bearing Slide Block Units, 8mm Bore Dia (Pack of 4)

Model: SCS8UU (Bearing No.: LMF8UU, Nominal Shaft Diamter (dr): 8mm) Aluminium Alloy Linear Ball Bearing Slide Block Units Light-weight housing and Chromium Steel bearing ball, good abrasion resistance, high precision and good strength Smooth moving, low friction, high rigidity and long working life Suitalbe for kinds of electronic equipment/guide bar, and pillar 1.provides SCSUU series Linear Ball Bearing Slide Block Units complementary to linear ball bearings.
2.They usually consist of a light-weight, aluminium housing to provide high strength and stiffness.
3.Compact design with High load carrying capacity, Linear Motion Bearing Unit is a rolling friction supporting element that usually used for linear motion mechanical parts with small friction.
4.Coordinate with Linear Motion Shaft, recirculating balls provide unlimited stroke at low friction movement, permit temperature within 80 degree Celsius.
5.It is great for 3D printer, CNC, and other applications.


Specification:
Unit No.: SCS8UU
Bearing No.: LM8UU
Slide Block Meterial: Aluminium Alloy
Bearing Ball Meterial: Chromium Steel
Cage Meterial: Nylon
Nominal Shaft Diamter (dr): 8mm
Slide Block Size: 34 x 30 x 22mm / 1.34 x 1.18 x 0.87inch (L*W*H)
Mounting Hole Size: M4
Mounting Hole Distance: 24 x 18mm / 0.94 x 0.71inch (B*C)
Static Load Capacity (Cor): 0.402kN
Dynamic Load Capacity (Cr): 0.265kN
Number of Pack: 4 Pcs
