gofanco Receiver (HDbitTPRO-RX, New v2.0) Unit for HDMI Extender Kit (Part# HDbitTPRO, v2.0) – Do Not Use with v1.0 Kit

gofanco Receiver (HDbitTPRO-RX, New v2.0) Unit for HDMI Extender Kit (Part# HDbitTPRO, v2.0) – Do Not Use with v1.0 Kit

NOTE: This item is ONLY the RECEIVER (RX) unit for the HDbitTPRO v2.0 extender kit. This package is equipped with a Receiver box, IR cable, power adapter and user’s guide. . *Important Note*: Version 2.0 is NOT backward compatible with the previous version Extender Kit NETWORK DISTRIBUTION – Connect up to 255 receivers per transmitter. Direct 1-to-1 connection, 1-to-many configuration through 1) Unmanaged/Dedicated Gigabit switches, 2) Smart Gigabit switches with VLAN to segregate video traffic from the rest of the LAN. Many-to-many configuration is also supported via VLAN setups. Note that each VLAN can only accommodate 1 transmitter (TX). We recommend gofanco 24-port video Ethernet switch (EthSwitch24P-2) ; Don't use home routers for this LOW BANDWIDTH USAGE – Support 1080p Full HD resolution; supports 480i/480p @60Hz, 576i/576p @50Hz, 720p @50/60Hz, 1080i/1080p @50/60Hz; Auto adjustment for different cable lengths to produce the best video/audio experience. Supports 2-channel Stereo Audio. We recommend using high performance pure COPPER gofanco CAT6 cables to ensure reliable performance: Search CAT6UTP-100/CAT6UTP-150 on Amazon IR Extension – Control your HDMI source device remotely; With the included IR cable, you can control your source device from a long distance, typically where the HDTV is located SIMPLE INSTALLATION – No driver required; Sturdy metal enclosure provides durability and minimizes EMI noise interference. FCC, CE & RoHS compliant. If you have any questions, click on our name in the buy box and select "Ask a Question" to reach our experienced technical support team in Silicon Valley

gofanco HDMI CAT5e/6 Extender with IR – 120m extends HDMI audio/video signals over one cost effective CAT5e/6 cable, while maintaining signal strength and superior audio/video quality. HDMI signal transmission can be delivered directly with 1-to-1 connection or with existing network Gigabit routers or switches. With HDBitT transport protocol, you can connect up to 30 Receivers per Transmitter to not only extend but split HDMI signals to multiple displays.

Notes:
- A good quality CAT5e/6 cable is essential in delivering quality content. CAT6 is recommended over CAT5e
- Network setup with multiple Receivers requires unmanaged Gigabit Ethernet switches for best performance. Dedicated unmanaged Gigabit Ethernet switches are recommended
- This package comes with one Transmitter and one Receiver. For one Transmitter to multiple Receivers setup over the network, 1080p Receiver(s) can be purchased separately

Specifications
- Video resolutions: 408i/480p @60Hz, 576i/576p @50Hz, 720p @50/60Hz, 1080i/1080p @50/60Hz
- Audio support: Digital stereo audio
- Transmission range: 1080p @60Hz up to 394ft (120m)
- Transport protocol: HDBitT
- HDMI 1.3 and HDCP 1.2 compliant
- Network cable: UTP/STP CAT5e/6/6a/7
- 3.5mm connector: IR Receiver (RX)
- Housing: Metal
- Power supply: 5V/1A DC
- Power consumption: 3 watts (RX)
- Operation temperature: 32 ~ 140° F
- Country of origin: China
- Regulatory approvals: FCC, CE, RoHS

What's in the Package
- HDMI HDBitT CAT5e/6 Extender with Loopout – RX (Receiver unit only)
- IR RX cable
- Power adapter
- User’s guide

Warranty & Support
- Limited One-Year Warranty and Lifetime Product Support
