ACTi B511A 12MP Video Analytics Indoor Hemispheric Dome Camera with SLLS, Fixed Lens, f1.65mm/F2.8, H.264, Dewarping, Built-in Microphone, MicroSDHC/

ACTi B511A 12MP Video Analytics Indoor Hemispheric Dome Camera with SLLS, Fixed Lens, f1.65mm/F2.8, H.264, Dewarping, Built-in Microphone, MicroSDHC/

View Mode: Fisheye View, Dewarped View, 270° Corner View, Multiple View, ePTZ View Built-in Analytics: Object Based Motion Detection, Tampering Detection, Shock Detection, Digital Auto Tracking, Object Line Crossing Detection, Object Enter Area Detection, Missing Object Detection, Unattended Object Detection, Object Loitering Detection Server-based Analytics: Object Line Counting, People Counting, Face Detection, Object Based Motion Detection, Tamper, Object Line Crossing Detection, Object Enter Area Detection, Missing Object Detection, Unattended Object Detection, Smoke Detection, Heat Map, Dwell Time, People Queue Detection Event Trigger: Video motion detection (10 included and excluded polygons regions), External device through digital input, Sound detection, Intelligent event detection Event Response: Notify control center, Go to ePTZ preset point or preset tour, Change camera settings, Command other devices, E-mail notification with snapshots, Play the audio file, Push notification to mobile device, Save video to local storage, Save video or snapshot to local storage, Upload video to NVR server, Upload video or snapshot to FTP server, Activate external device through digital output

ACTi B511A 12MP Video Analytics Indoor Hemispheric Dome Camera with SLLS, Fixed Lens, f1.65mm/F2.8, H.264, Dewarping, Built-in Microphone, MicroSDHC/MicroSDXC, PoE/DC12V, DI/DO, Built-in Analytics

• Day & Night with Superior Low Light Sensitivity and Adaptive IR LED
• Fisheye Lens with f1.65mm/F2.8
• 360°/180° Panorama View with Dewarped Streaming
• Digital Auto Tracking
• Overview, Zoom and Tracking (OZT)

• Maximum Resolution: 12MP
• Image Sensor: Progressive Scan CMOS
• Sensor Size: 1/1.7"
• Effective Pixels: 4072x3046
• Mechanical IR Cut Filter: Yes
• IR Sensitivity Range: 700-1100nm
• IR LED: Adaptive IR LED x12 (850 nm)
• IR Working Distance: 20m
• Horizontal Resolution: 2250 TV Lines
• S/N Ratio: 56 dB
• Lens Mount: Board
• Horizontal Viewing Angle: 198.5° (overview area)/121.1° (high detail area)
• Vertical Viewing Angle: 198.5° (Fisheye View)
• Compression: H.264 (Baseline/ Main/ High profile), MJPEG
• View Mode: Fisheye View, Dewarped View, 270° Corner View, Multiple View, ePTZ View
• Bit Rate: 128Kbps-12Mbps (per stream)
• Wide Dynamic Range: Extreme WDR (130 dB)
• Digital Noise Reduction: 2D+3D DNR
• Privacy Mask: 8 configurable regions
• Text Overlay: Yes
• Audio Type: 2-way, Built-in Microphone, Mic-in, Line-in, Line-out
• Audio Compression: 8 kHz, 16 bit encoding, Mono, PCM, G.711
• Ethernet Port: 1x RJ-45 connector
• Profile S, Profile G, Profile T, Profile Q
• Power Source: PoE Class 3 (IEEE802.3af), DC 12V
• Power Consumption: 7.17W (PoE)
• Starting Temperature: -10°C~50°C
• Operating Temperature: -10°C~50°C
• UPC: 888034008939
• EAN: 4710751962606
• Dimensions: 5.9"x1.7"
• Weight: 0.98 lb
