APIELE 16mm Latching Push Button Switch 12V DC On Off Black Shell with LED Angel Eye Head for 0.63" Mounting Hole with Wire Socket Plug Self-Locking (

APIELE 16mm Latching Push Button Switch 12V DC On Off Black Shell with LED Angel Eye Head for 0.63" Mounting Hole with Wire Socket Plug Self-Locking (

GET NEW ONE IF NOT MAN MADE BROKEN IN 3 YEARS SINCE YOU PURCHASE THE SWITCH. Brand New 16mm Latching Switch; Black Shell Ring LED; LED voltage: 12V only, Hole size required: 0.63''/16mm Latching Push Button Switch: Push it, ON; Push it again, OFF. Contact Configuration: 1NO1NC； 12 volt switch Electrical life: 200 thousand times. Mechanical life: 1,000,000 cycles 12v on off Switch; High quality metal material & IP65 waterproof protection can be used in wet or dusty enviroment.

Latching switch

The Latching switch will remain on once it ispressed and stay on until it is pressed again.

Specification:

- Switch Rating: 5A/250VAC

- Operation Temperature: -20℃~ +55℃

- Mechanical life: 1,000,000 cycles

- Electrical life: 200,000 cycles

- Panel thickness: 1 - 10mm

- Protection level: IP65, IK10

- Mounting Cut Hole: 16mm

- Operation Type: Latching

- Switch Contact: 1NO 1NC

- LED Rating: 15mA, AC/DC 12V

- LED Pattern: Ring Indicator

- Contact Material: Silver alloy

- Button Material: Aluminium Oxide

Note:

- The switch come with a rubber O-ring which makesit splash resistant but it can NOT be submerged underwater.

Packing Include: 1 x push button switch ,1 x pigtail socket,1 x Wiring diagram
