JacobsParts NodeMCU Lua ESP8266 ESP-12F CP2102 WiFi Development Board

JacobsParts NodeMCU Lua ESP8266 ESP-12F CP2102 WiFi Development Board

You may need the CP2102 driver available from the Silabs website. It is free and easy to install. This board features the ESP8266 ESP-12F but has all of its pins broken out. This enables the ESP8266 to be breadboard compatible. It also has an integrated micro-usb port which makes powering and programming the chip far easier compared to having to use a usb-to-serial adapter. The NodeMcu firmware can be loaded easily if you want to develop programs in Lua. It is also compatible when other leading micro-controller development platforms. This board has a female Micro-USB port on the board for power and program uploading. This port type is very common on many consumer electronics and on smartphones. Flashing this device is easy. To flash, just hold the flash button and perform the flash using firmware programming software. • Uses CP2102
• NodeMCU has built-in USB-TTL serial with reliable industrial strength CP2102
• CP2102 provides superior stability on all supported platforms
• Communication interface voltage: 3.3V
• Antenna type: Built-in PCB antenna is available
• Wireless 802.11 b/g/n standard
• WiFi at 2.4GHz, support WPA / WPA2 security mode
• Support STA/AP/STA + AP three operating modes
• Built-in TCP/IP protocol stack to support multiple TCP Client connections (5 MAX)
• D0 ~ D8, SD1 ~ SD3: used as GPIO, PWM, IIC, etc., port driver capability 15mA
• AD0: 1 channel ADC
• Power input: 4.5V ~ 9V (10VMAX), USB-powered
• Current: continuous transmission: 70mA (200mA MAX), Standby:
