Ultrasonic Flow Meter Flowmeter with SD Card Data Logger DN25~100mm TS-2 Small Size Clamp-on Transducer

Ultrasonic Flow Meter Flowmeter with SD Card Data Logger DN25~100mm TS-2 Small Size Clamp-on Transducer

(1)【Type of liquid：】Single liquid can transmit ultrasound, such as water, sea water, sewage, oil, alcohol, etc. (2)【Pipe material：】Steel, stainless steel, cast iron, copper, PVC, aluminmum, glass steel, etc. Liner is allowed. (3)【Installation methods: 】Wall mounting and Two ways of Din-rail mounting ◆Ultrasonic Flow Meter Flowmeter with SD Card Data Logger DN25~100mm TS-2 Small Size Clamp-on Transducer◆

◆Shipping Policy : Liquid not Included During the Shipping◆

◆This type of Ultrasonic flow meter package with TS-2 small type Transducer (size: 42*25*32mm) for Pipe Diameter DN25~100mm, Temperature : -30~90C◆

Technical Specifications:
◆Principle: Transit-time ultrasonic flowmeter
◆Accuracy: ±1%
◆Display: 2x20 character LCD with backlight, support the language of Chinese, English, Italy, Turkish
◆Signal output:◆
1way 4-20mA output, electric resistance 0-1K, accuracy0.1%
1 way OCT pulse output(Pulse width-1000ms, default is 200ms))
1 way Relay output
◆Signal input:◆
3 way 4-20mA input, accuracy 0.1%, acquisition signal such as temperature, press and liquid level
Connect the temperature transducer P100, can finish the heat/energy measurement.
◆Data Interface:Insulate Rs485 serial interface, upgrade the flowmeter software by computer, support the MODBUS.
◆Special Cable:Twisted-pair cable, generally, the length under 50 meters, select the Rs485, transmission distance can over 1000m
◆Pipe Installation Condition◆
Pipe material:Steel, stainless steel, cast iron, copper, cement pipe, PVC, Aluminum, glass steel product, liner is allowed
Pipe diameter:DN25 to 100mm
Straight pipe:Transducer installation should be satisfied: upstream10D, downstream5D, 30D from the pump.

Standard Configurations:
1. Ultrasonic Flowmeter
2. TS-2 Transducer
3. 2 x5m Signal cable
4. Steel Belt
5. Certificate of Warranty
6.SD Card Data Logger
