PCIe to USB 3.2/USB 3.1 Gen 2 Card 10Gbps 5-Port (3X USB C -2X Type A) PCI Express Expansion Card PC Internal Hub for Windows 10/8/7 Linux and MAC OS

PCIe to USB 3.2/USB 3.1 Gen 2 Card 10Gbps 5-Port (3X USB C -2X Type A) PCI Express Expansion Card PC Internal Hub for Windows 10/8/7 Linux and MAC OS

Insert the PCIe USB 3.2/USB 3.1 gen 2 card into the PCI Express (4X) slot, you can upgrade desktop computer to 3x USB C and 2x USB A ports.On this basis, make more devices connected to computer systems,such as external hard drive,printer,scanner,tablet,smart phone,USB VR,game controller,etc SuperSpeed USB 3.2: 2 USB Type-C ports and 2 USB Type-A ports share 10Gbps bandwidth, the bottom USB Type-C port exclusive speed 10Gbps bandwidth. External USB device supports data transfer rates of up to 10Gbps when used on its own. This PCIe card is a must-have for external hard drives and ideal for file transfers. (Note: Actual transfer speeds may be limited by the connected device). Extensive compatibility: The card supports PCI Express X4 ,X8,and X16 slots. USB 3.2 ports are backward compatible with 3.0 and 2.0. The operating system is compatible with Windows 7,8,and 10 (32/64-bit) and Mac OS 10.8.2 or higher. When the PCIe usb card is installed,Win 10,Mac OS and Linux don't need a driver, Windows 7 system must install the drive Intelligent protection: Each interface has independent insurance,with over-current and short-circuit intelligent protection to protect your computer equipment. In addition, a low-power USB device connection doesn't require an external power supply. Easy to install,The card can be powered directly from the PCIe slot on the motherboard What You Get: 1x USB 3.2 PCIE card,1x CD drive,2x installation screws,1x user manual and Provides 1 year of product-care 5-Port SuperSpeed PCIE USB 3.2 Gen 2 Card allow users add USB 3.2 superspeed total-10Gbps ports on desktop computers for video, audio, photos or files transfer. Build in Self-Powered Technology for high power-consuming data devices.It is a perfect choice for Cameras,VR system,Flash Drive,USB SSD/HDD Enclosures and more USB device.

Features:

1.Extend with 3 USB Type C, 2 USB 3.2 Type A downstream ports for standard desktop PC.

2.Support UASP: 70% faster than traditional USB 3.0 using UASP. UASP transfer protocol can speed up the read and write speed of SSD hard disks.

3.No need any extral power.Plug & play and hot swapping capability.

4.Date transfer rates up to total 10Gbps (1x USB Type-C port and 2x USB Type-A ports share 10Gbps ,rest 2x ports share another 10Gbps )- 10x faster than USB 3.0.

5. Supports simultaneous operation of multiple USB 3.2/3.1, USB 3.0, USB 2.0 devices.

6. The PCIe usb card has 4 power supply modules, no additional power supply is needed, and it allows five mobile hard drives to transmit data at the same time.

7. Built-in ASM 3142 chip.

(Please note that it is PCI-E 4X card and does not support PCI-E 1X slot.)

Operating Systems

1.Compatible with Windows XP/Vista/ 2008/7/Windows 8/10/11,Linux and Mac OS 10.8.2 .

2.Windows XP/Vista/ 2008/7 need to install the driver from the included CD drive.

You'll receive :

1 x USB 3.2 PCIe card

1x CD drive

2x installation screws

1x User manual
