BFMore Mini 5.0MP POE Explosion Proof Camera Car Network P2P Outdoor Corrosion Protection Security H.265

BFMore Mini 5.0MP POE Explosion Proof Camera Car Network P2P Outdoor Corrosion Protection Security H.265

H.265/H.264 HD 5.0MP 2592x1944 IP Camera Explosion proof level CT6, Water-proof level IP66 Housing material: High-strength stainless steel structure Using tempered flat glass to make sure it’s strong and durable

1) Housing Specification:

Material: Stainless steel 304

Explosion-proof Level: CT6

Water-proof Level: IP66

High temperature proof,corrosion proof,bullet-proof glass

With two holes at the bottom, diverse and easy installation:

2) Camera Specification:

Processor: 3516EV300

Image sensor: 1/2.8" 5.0 MP 3516E CMOS

Lens: 3.6mm

IR Distance: 30 meters at most

Power Supply: DC 48V

Working temperature: -20 degrees Celsius to +60 degrees Celsius

Video Codec: H.264 main profile and baseline

Video Resolution: First stream: 2560x1920/2560x1440, Second stream: 800x600/800x448

Frame Rate:PAL: 15fps(50HZ),NTSC:15fps(60HZ)

Video Compression: 32Kbits/s ~ 6Mbits/s

Interface: RJ45 interface

Network Protocol: TCP/IP, HTTP, TCP, ICMP, UDP, ARP, IGMP, SMTP, FTP, DHCP, DNS, DDNS, NTP, UPNP, RTSP, ect.

Access Protocol: ONVIF 2.1

Motion detection: 4 respective regions at most

Alarm linkage: Alarm picture sent by E-mail, alarm images uploaded to FTP server

Snapshot: Supports capturing images regularly to the FTP server

User management: Provides three levels of rights management (admin, user, guest). Supports modify login user name and password

Application：With the adoption of stainless steel and explosion-proof enclosure, this camera is applied to monitor work sites where there is flammable and explosive gas mixture, such as coal mining, petro chemical plant, gas station, medicine, ship, fireworks factory, food storage warehouse, etc.
