BOJACK 7-70V PWM DC Motor Speed Controller Control 30A

BOJACK 7-70V PWM DC Motor Speed Controller Control 30A

PWM frequency: 12KHZ Wide voltage 7-70V, high current 30A design, wide application range, on-board switch with operation, stop and brake function, adjustable potentiometer soft cable can be separated, the line length is 15CM Optimized circuit design. Wide adjustment range of duty cycle, smooth adjustment of the motor without bath noise and vibration, with power indicator, stable circuit design and suitable for long-term work. Imported high-voltage MOS tube, three 100V high-frequency low-resistance capacitors, car fuses, parameters are not easy to heat and easy to replace, standard aluminum housing, protect internal circuits and components for long-term durability. Drive current: maximum 30A (working voltage and high current should be relatively reduced, please use with power) Product Name :DC Brush Motor Speed Controller

Applicable voltage range: DC 7-70V
(70V is the maximum operating voltage please leave margin while using)

Control power: 12V within 300W ; 24V within 400W ; 48V within 450W ; 72V within 500W

Drive current: Maximum 30A(Current need to reduce relatively while working voltage is high)

Duty cycle adjustable range: about 1% -100%

PWM frequency: 12KHZ

Note: This product is DC brush motor speed controller, can not access AC power and drive brushless motor.
