AITRIP 2PCS Pro Micro ATmega32U4 5V 16MHz Type-C Development Module Board with 2 Row pin Header Compatible arduino Leonardo Replace ATmega328 Pro Mini

AITRIP 2PCS Pro Micro ATmega32U4 5V 16MHz Type-C Development Module Board with 2 Row pin Header Compatible arduino Leonardo Replace ATmega328 Pro Mini

ATmega32U4 running at 5V/16MHz Supported by IDE v1.0.1 Rx and Tx Hardware Serial Connection 4 x 10-bit ADC pins, 12 x Digital I/Os On-Board Type-C connector for programming

Features:

ATmega32U4 running at 5V/16MHz

Recommend power supply for board: 6-7V, less than 9V

On-Board  Type-C connector for programming

4 x 10-bit ADC pins, 12 x Digital I/Os

Rx and Tx Hardware Serial Connections

How to use?

1. Connected to computer. (If this module cannot be recognized by your computer, please refer to this link to install the driver)

2. Opened Ard IDE and loaded Blink sketch.

3. Set board to Leonardo and selected the appropriate COM port (It showed up in the list already identified as a Leonardo).

4. Connected an LED to pin 9 and modified the sketch accordingly.

5. Hit upload and within a few seconds having a blinking LED.

Package Includes:

2 x Pro Micro ATmega32U4 5V 16MHz Module ( Type-C)
