LASER TREE Laser Engraving Module, 5W Output Optical Power 450nm Laser Head for CNC Laser Engraver/Laser Cutter Machine, DIY Laser Engraving Tool

LASER TREE Laser Engraving Module, 5W Output Optical Power 450nm Laser Head for CNC Laser Engraver/Laser Cutter Machine, DIY Laser Engraving Tool

【Main Performance】a. Engraving Mirror Stainless Steel, no need to Paint Black; b. Very Fast Engraving Speed: 23mm focal length, engrave 304 stainless steel at speeds up to 800mm/min; c.Excellent Cutting Ability: Cutting 4mm thick plywood by one pass at a Speed of 120mm/mm. 40W is the machine power and 5W is the output laser power. 【Original Diode】The Blue Laser module with original diode,high stability, high efficiency, high quality, 20,000 hours life time! Beam compressed spot technology to reduce the focal area and make it more accurat. The solution make high engrave speed and high precision possible. Metal cutting air outlet, resist flames. This laser module comes with a magnetic eye shield that filters 97% of UV rays to protect your eyes and those around you. 【Easy to Use】Wavelength: 450nm; Input: DC 12V 1.8A(1.5A-2A); Power adjustable: Support 5V PWM modulation; Input port: XH2.54-3P socket; Control line installation method: Pluggable; 23mm Fixed focus laser head, connection is convenient; Output Power:5000 mW, Class:4 【Widely Compatibility and Application】The laser module is compatible with most laser engraver cutter brands on the market, e.g. AtomSt**k, Ort*r, Nej*, etc. and LaserGRBL, LightBurn, and other engraving software, supports Win XP / Win 7 / Win 8 /Win 10 operating system, supports MACOS system; It can be used to engrave MDF, wood, paper, leather, bamboo, plastic, rubber, alumina, stainless steel, etc. (🔺Unable to engrave with blue/purple/white/transparent material, aluminum without oxide layer) 【Comprehensive & Trustworthy After-Sales Service】Note🔺:Please wear appropriate safety glasses when use laser module to prevent laser light, even any reflections from entering to the eye. If you need pre-sale consultation or encounter any problems,please feel free to contact us directly.We have professional engineer team will troubleshoot and solve the problem for you! Note: Regular cleaning and maintenance of the lenses will maintain good cutting results and achieve a longer service life. Upgraded Laser Module, LASER TREE 23mm Fixed Focus Balance Engraving and Cutting Head, Laser Engraver Module 5W Optical Power with Metal Wind Gathering Hood, Suitable for Laser Engraver Machine
Product Features:
1.Engraving Mirror Stainless Steel, no need to Paint Black.
2.Very Fast Engraving Speed: 23mm focal length, engrave 304 stainless steel at speeds up to 800mm/min.
3.Excellent Cutting Ability: Cutting 4mm thick plywood by one pass at a Speed of 80-100mm/s.
4.Magnetic eye protective cover: It allows you to see the laser module in action without the need for eye protection and is easy to disassemble without screws.
5.Metal cutting air outlet: Which does not generate heat and can resist flames.
Specification:
Material: Aluminum alloy
Effect Output Power: 40W
Output Optical Power: 5W
Electric Power: 12V 1.8A(1.5A-2A)
Focus Length: 23mm
Interface: XH2.54-3P socket
Power Adjustable: Support 5V PWM modulation
Function: Engraving/Cutting
Module Size: 40*40*121mm
Module Weight: 240g
