Charging Module, Battery Charging Board IP2312 Type C Input 5V to 4.2V 3A Polymer Ternary Lithium Battery Fast Charging Board

Charging Module, Battery Charging Board IP2312 Type C Input 5V to 4.2V 3A Polymer Ternary Lithium Battery Fast Charging Board

IP2312 uses full CC/CV charging mode, 3A charging current, 4.2V charging cut-off voltage. When the battery voltage is lower than 3V, it enters the trickle charging mode, charging the battery with a charging current of 100mA. When the battery voltage is greater than 3V, enter the constant current charging mode, and charge the battery with the set constant current charging current. When the battery voltage is close to 4.2V and the charging current is less than 300mA, it enters the constant voltage charging mode.When the battery is fully charged, if it detects that the battery voltage is lower than 4.1V, it will start to charge the battery. Warm Tip: We have always adhered to the customer first service attitude. If you have any problems after receiving our product, please contact the customer service below, and we will provide you with satisfactory solutions at the first time. Specification:
Item Type: Charging Module,lithium battery charging board
Main Control Chip: IP2312
Input Voltage: 4.5~5.5V
Charging Cut-Off Voltage: 4.2V
Charging Current: 3A (The Current Can Be Changed by Adjusting the Resistance)
Indicator Light: Red: Working Indicator Light. Blue: Full of Indicators.
Conversion Efficiency: 3A 93%, 2A 94%, 1A 95%

Package List:
1 x Battery Charging Board

Note:
1. Not applicable to 3.2V lithium iron phosphate batteries.
2. This product does not have the power indicator function, and does not have the battery protection function.
3. After entering the constant voltage mode, the charging stops every 4 minutes, and the battery voltage is detected to be higher than 4.15V:
 the charging is stopped if the battery voltage is higher than 4.15V; otherwise, the charging is continued, and the detection is performed after 4 minutes.
