PID Temperature Controller, Digital Display REX-C100 Temperature Controllers Box with Solid State Relay SSR 40DA and K Thermocouple Probe, Universal

PID Temperature Controller, Digital Display REX-C100 Temperature Controllers Box with Solid State Relay SSR 40DA and K Thermocouple Probe, Universal

【Temperature Control Advantages】Our REX-C100 digital PID temperature controller kits can detect temperature range: 0~1300°C.Note: you will need to buy and install 400-1300°C probe sensor(not included in the package). 【Quality Material】The temperature controller probe is sealed with stainless steel and resin, waterproof and rust-free. The other part is made of high-quality metal and plastic,it is environmentally friendly and durable. 【Clear Digital Display】This Temperature Controller is adopted industrial-grade professional self-tuning PID technology, support reading with Centigrade or Fahrenheit unit, be able to display measured and Controller temperature.Compared with the traditional PID control, it has a rapid temperature control, small overshoot and high precision. 【Wide Application】Our temperature controller can widely applied to IR far infrared oven equipment, drying equipment, printing and dyeing equipment, UV curing machine, plastic machinery, small water tank, and other scenarios that require electric heating and temperature control. 【Product Including】REX-C100 PID temperature controller, SSR 40DA solid state relay,1m 0~400°C K-type probe sensor, white heat sink. Specifications:

White Heat Sink
Screw Thread: M4
Roof: 50mm x 60mm.
Foot: 80mm x 50mm.
Height: 50mm

K Type Thermocouple
Temperature rang :0-400℃
Sensor Dia: 0.18inch (4.5mm)
Cable Length: 3.3ft(1m)
External Shielding: Insulated Shielding
Internal Insulation: Fiberglass
Screw Thread: M6

40DA SSR Solid State Relay
Load Voltage: 24~380VAC
Load Current: 40A
Input Voltage: DC 3~32V

Temperature controller
Measuring Accuracy:±0.5%FS
Resolution: 14 bit
Sampling Cycle: 0.5 Sec
Power: AC 110V-240V 50/60HZ
Detecting Temperature Range: 0℃~1300℃
Service Environment: 0℃~50℃
Non-corrosive gas environment :30 ~ 85% RH
Insulation resistance : 1500V AC/min
Relay output: contact capacity 250V AC 3A (resistive load)
Cold-end compensation tolerance: +/-2 ℃(can be modified by software in 0~50 ℃)

Package Included:
1 x PID Temperature Controller
1x 40DA SSR Solid State Relay
1 x K type Thermocouple
1 x White Heat Sink
