Thermalright Phantom Spirit 120 CPU Air Cooler, 7 Heat Pipes CPU Cooler,Dual 120mm TL-C12B V2 PWM Fans, AGHP 4.0 Technology,for AMD AM4 AM5/Intel

Thermalright Phantom Spirit 120 CPU Air Cooler, 7 Heat Pipes CPU Cooler,Dual 120mm TL-C12B V2 PWM Fans, AGHP 4.0 Technology,for AMD AM4 AM5/Intel

【Brand Overview】Thermalright is a Taiwanese brand with more than 20 years of development history. It has a certain popularity in the domestic and international markets and has a decisive influence in the cooler market. We have been focusing on the research and development of computer accessories. The R&D product line includes: CPU coolers, case fans, silicone pad, thermal paste, mounting brackets, accessories and other products. 【Product specification】PS120; CPU Cooler dimensions:125(L)x135(W)x157(H)mm (4.92x5.31x 6.18 inch) ,heat sink material: aluminum,the main body is made of anodized black frosted top + finely carved pure copper base technology, avoiding the memory design, the main body is fully aluminum fins, bringing maximum heat dissipation area. combined with the high thermal conductivity of the thermal paste, which can perfectly perform the cooler's most powerful cooling effect. 【AGHP technique】7x6mm heatpipe with AGHP upgraded 4th generation technology, the Inverse gravity effect caused by vertical / horizontal orientation. Up to 20000 hours of industrial service life, S-FDB bearings ensure long service life of air-cooler radiators.UL class a safety insulation low-grade, industrial strength PBT + PC material to create high-quality products for you. The height is 154mm, compatible with a wide range of chassis models. 【PWM Fan】 TL-C12B V2; Standard size industrial grade PWM performance PC fan: 120x120x25mm; Fan speed (RPM): 1500rpm±10%; Power port: 4-pin; Voltage: 12V; Air flow: 66.17CFM (max); Noise level ≤25.6dB(A), high performance fan combined with efficient heat dissipation The cooling body of the unit gives you the best cooling effect. 【Compatibility】CPU cooling slot support: Intel: LGA1700/1851/1150/1151/1155/1156/1200/2011/2066, AMD: AM4/AM5;for different CPU slot platforms, provide the corresponding mounting plate or fasteners, can be combined with the installation instructions or follow the tutorial to get on the machine.

Parameters

Model: PS120

Heatsink size: 125*135*157mm

Fan size: 120*120*25mm

Rotational speed: 1500RPM±10%

Noise ≤25.6dBA

Airflow: 66.17CFM(MAX)

Wind pressure: 1.53mm H2O(MAX)

Fan connection: 4PIN PWM

Voltage: 12V DC

Current: 0.2A

Bearing Type: S-FDB Bearing

Package Details

Main Body x 1, TL-C12 V2 Fan x 1,Fan Hook x 2, AMD Bracket x 2, INTEL Bracket x 2, INTEL LGA17XX/115X Backplane x 1, Black Cylinders x 4, Screws x 4, TF7 Thermal Paste x 1, Manual x 1
