XICOOLEE DC5V Cooling Fan for Jetson Nano Developer Kit 4Pin PWM Adjustable Speed Strong Cooling Air Fan with Reverse-Proof Connector 40mmx40mmx10mm

XICOOLEE DC5V Cooling Fan for Jetson Nano Developer Kit 4Pin PWM Adjustable Speed Strong Cooling Air Fan with Reverse-Proof Connector 40mmx40mmx10mm

This 40mm fan is a high-quality cooling fan, mainly used for cooling on Jetson Nano This 40mm fan is a high-quality cooling fan, mainly used for cooling on Jetson Nano Compact size: Its size is 40mmx40mmx10mm, the working voltage is 5V DC, the rated current is 0.25A, and the rated power is 1.25W PWM speed regulation: The cooling fan for Jetson Nano supports PWM speed regulation, users can freely control the fan speed according to their needs, so as to achieve the best cooling effect and noise control Easy installation: The DC fan adopts four-wire reverse-proof connection 2510-4P terminal, which is suitable for Jetson Nano. In this way, it is convenient for users to install quickly Overview:

This 4010 40mm DC fan is a high-quality cooling fan, mainly used for cooling on Jetson Nano.
The Jetson Nano fan adopts ball bearings, featuring high efficiency, low noise and long life.
Its size is 40mm*40mm*10mm, the working voltage is 5V DC, the rated current is 0.25A, and the rated power is 1.25W.
The speed of the fan can reach 7600 RPM, and can provide a maximum air volume of 0.22m³/min,
thereby effectively reducing the temperature of the device and protecting the stability and running time of the device.
In addition, it also has the advantages of easy installation, excellent heat dissipation performance and excellent reliability, making it an ideal cooling fan choice.


Specifications:

Dimension: 40mm(L)x40mm(W)x10mm(H)
Weight: 13±4g
Rated Voltage: 5V DC
Start-up Voltage: 3V DC
Operating Voltage: 3V~7V DC
Rated Speed: 7600rpm/min ±10%
Rated Current: 0.25(Max:0.3)A±0.02A
Rated Power: 1.25(Max: 1.5)W
Max Airflow: 0.22(Min:0.22)m³/min
Max Static Pressure: 3.4(Min: 3.05)mm-H₂O
Noise Level: 27~30dBA
Maximum Voltage: 7V
Locked Rotor Protection: Lock automatic power-off protection
Polarity Protection: VCC and GND reverse polarity protection
Bearing: Dual Ball Bearing
Fire Rating: 94V-0
Lead Wire: Red(+) Black(-) Yellow(FG) Blue(PWM)
Connector: 2510-4p terminal


Package Contents:

1.SG-F4010-A x1
2. M3x10 Cross flat head screws x4
