BaseWish 7W 1W Long Range FM Transmitter with LCD & 3.5mm Audio Cable - Ideal for Drive-in Church, School & Supermarket Events, Light Shows &

BaseWish 7W 1W Long Range FM Transmitter with LCD & 3.5mm Audio Cable - Ideal for Drive-in Church, School & Supermarket Events, Light Shows &

FCC Certified(FCC ID: 2ASVO05B7CT200) with two power modes (1W and 7W). High Stability with next-generation integrated NC FM stereo radio transmitter chip BH1415, built-in PLL advanced modulation system, audio pre-emphasis, limiter and low pass filter circuit. Clear Stereo Sound with AT89C2051 and AT24C02 control panel, three power amplifiers (two 2SC3355 and one 2SC2053) to ensure great sound quality output effect. Excellent Heat Dissipation with high quality aluminum alloy material, lightweight and excellent heat dissipation. Easy to Use with LCD display to show transmission frequency, easy to adjust and intuitive.

Specifications:

Tuning Step: 100Khz/0.1Mhz

Power Supply: 12V DC (The current load of power supply should over 2A)

Stability of Frequency: ±10ppm（-10℃~+50℃ ）

Signal to Noise Ratio: >65dB

Frequency Response：50Hz-15000Hz

Output Impedance: 50 ohm

Audio Input Connector: 3.5mm

Mic Input Connector: 3.5mm

Package includes:

1x 7W/1W FM Transmitter

1x Power Supply

1x 3.5mm Audio Cable

1x English manual
