Surpass Hobby Sensored Brushless Motor and ESC Combo for TRX4M 1/18 Crawler Car Upgrades(3500KV)

Surpass Hobby Sensored Brushless Motor and ESC Combo for TRX4M 1/18 Crawler Car Upgrades(3500KV)

Specially designed for 1/18 RC Crawler car with excellent start-up,acceleration and linearity features. Speed close-loop control to the power system of rock crawle, the lowspeed torque ls very strong, adjustable Drag Brake (Up to 200%),Enhanced climbing and speed control. Improved efficiency and reduced noise. Twice the braking power of standard brushless systems, ensuring superior downhill control. Powerful Low-Speed Torque & Smooth Operation: Intelligenttorque output &speed closed-loop control for easy control, delivering strong torque even at extremely low speeds for smooth and responsive driving. Multiple protection features: Low voltage cut-offprotection for lithiumor nickel battery/Over-heat protection /Throttle signal loss protection /Motor blocked protection.The strong resistant current capability, excellent heat dissipation. Built-in switch-mode BEC 5V/500mA for usage with high torque andhigh voltage servos. Note: The BEC supports up to 8.4V output for low-current applications only (e.g., powering receivers or sensors). For high-current servos, we recommend using 6V–7.4V for reliable and safe operation.

Surpass Hobby GECKO 2030 Sesored Brushless motor and ESC Combo for TRX4M 1/18 mini Crawler Upgrade

Features:

 Comprehensive Protection System

Low Voltage Protection – Prevents over-discharge.

Overheat Protection – Reduces power if overheating occurs.

Overvoltage Protection – Limits excessive voltage input.

Overcurrent Protection – Prevents damage from high current.

Phase Loss Protection – Shuts down ESC if a phase wire disconnects.

Throttle Signal Loss Protection – Stops runaway scenarios.

Motor Disconnection Protection – Alerts and limits power if motor communication is lost.

ESC Specifications:

ESC Type: Rocket RC 30A Brushless ESC

Continuous/Peak Current: 30A / 80A

Supported Motors: Only compatible with Brushless Sensored 180 Motor

Scale Compatibility: ≤1/18 scale vehicles

Battery Support: 1-2S LiPo; 3-6S NiMH

BEC Output: BEC 5V/500mA

Size: 17.9mm×26mm×10.4mm

Weight: 9.5g

MOTOR Specifications:

Motor KV: 3500KV

Motor Type: Brushless Sensored 2030 Motor

Max Watts：120W

Max Voltage:8.4V

Max Amps:10A

Rotor Poles: 2S

Size: 20mm×31mm×20.5mm

Weight: 35g
