RAROZEEK Generator Avr Automatic Voltage Regulator Compatible with Honda Champion Compatible with Firman Generator Parts 3500 4000 watt 2KW 3KW 4KW

RAROZEEK Generator Avr Automatic Voltage Regulator Compatible with Honda Champion Compatible with Firman Generator Parts 3500 4000 watt 2KW 3KW 4KW

【Fits for】:Compatible with Honda part# 290440009, EC2500. This rectifier can also be used for cloned Compatible with Honda engines and generators ranging from 2kw to 4kw (3000, 3200, 3300, 3500, 3550, 3600, 3650, 4000, 4250, 4375, 4400, 4500, 4550, 4650, etc.)Compatible with Firman for Generac Compatible with Briggs & Stratton for DuroMax 2kw to 4kw 2000W 3000W 3500W 4000W Generator AVR. Homelite 290440011. Predator 4375 4650.Part#: 122.190200.00 122.190200.03 30060-Y025110 【Applicable for】:Compatible with Honda Predator Compatible with Champion Compatible with Firman DuroMax Generator Parts 3500 4000 watt 2KW 3KW 3.5KW 4KW 30060-Y025110 Homelite 290440011 4375 4650 【Product size】:Mounting hole diameter: 6mm (0.23inch); Center distance between two mounting holes:98.5mm(3.87inch).Before purchasing, Please check the corresponding size 【Attention】: You can get the voltage output you need by turning the cooper voltage adjustment screw in blue parts 2.When connecting the AVR to the carbon brush, please make the side of the notch face the side with the word 【Package include】:1×AVR and 2×Generator carbon brush Fit for:
Predator Compatible with Champion Compatible with Firman 2-4KW

Product Parameters：
Maximum Output: DC 90V 2.5A
Excitation Voltage: 90V
Feedback Voltage: 16-20V
Frequency: 50/60Hz
ACVoltage Output: 120V/240V
Auto Voltage Adjusting Accuracy: ±1%
Maximum Temperature Rise: 130C or 266F

Product Size:
Mounting hole diameter:6mm(0.24inch)
Center distance between two mounting holes:100mm

Product Performance:
Stable output
Easy installation and disassembly

Cautions:
1.You can get the voltage output you need by turning the cooper voltage adjustment screw in blue parts
2.When connecting the AVR to the carbon brush, please make the side of the notch face the side with the word(as shown in the picture)
3.Check the size of the mounting holes for your machine before purchase
