SIGANDG 70/10 uF 70+10 MFD 370V or 440V CBB65 Dual Run Start Round Capacitor 70 10 uF MFD 370 440 Volt VAC for Condenser Straight Cool or Heat Pump

SIGANDG 70/10 uF 70+10 MFD 370V or 440V CBB65 Dual Run Start Round Capacitor 70 10 uF MFD 370 440 Volt VAC for Condenser Straight Cool or Heat Pump

SIGANDG 70+10uF ±6% 370V/440V AC Capacitors, CBB65 Dual Run Round Capacitor, used in the air conditioners, compressors and motors Operating Temperature: -40℃ to +70℃ / -104℉ to +158℉ Safety Protection Level: S1.Engineered for Safety 10000 AFC Anti Explosion Pressure Switch Dimension: diameter 2.36 inch, height 4.33 inch Three terminals on the top are labeled "Herm"/"H" for the compressor motor, "Fan"/"F" for the fan, and "C" for the common line. SIGANDG CBB65 AC Motor Run Capacitors 80+7.5 UF 80/7.5 MFD 370/440VAC

Model:
CBB65 (Universal model)

Tolerance:
±6%

Capacity:
70/10uF

Rated Voltage:
370/440V AC

Frequency:
50/60Hz

Shell Material:
metal

Dielectric Material:
metallized polypropylene film

Use:
This capacitor is used for start-up and operation of AC motors with frequency of 50Hz/60Hz
such as air conditioners, compressors and motors.

Strong Point:
It is small in size, lightweight, heat resisting and anti-explosion.

Principle:
A dual "run capacitor" supports two electric motors, such as a fan motor and a compressor.
Dual run round capacitors are used to start and run the unit more efficient.
It saves space by combining two physical capacitors into one case.

Replacement:
Capacitors can be used to substitute oval shape one with the same MFD and Volt specs.
A 440 volt capacitor can be used in place of a 370 volt, as it is build better, but the 370 can’t be used in place of a 440 volt.
