ELP 4K HDMI USB Fisheye Camera for Computer Mini Lightburn Camera for Laser Engraver Type-C HDMI Display Simultaneous USB2.0 Webcam 2X Digital Zoom

ELP 4K HDMI USB Fisheye Camera for Computer Mini Lightburn Camera for Laser Engraver Type-C HDMI Display Simultaneous USB2.0 Webcam 2X Digital Zoom

3 Display Modes, USB mode / HDMI mode / USB & HDMI mode simultaneously display. Ultra HD Camera 4K, Max resolution 3840(H) x2160 (V), can drive 3840x2160 30fps at H.264/MJPEG/YUY2 . 2X digital zoom with high quality 1/2.8” IMX415 Color CMOS image Sensor. With wide angle 1.56mm fisheye lens, HFOV about 200degree. H.264/MJPEG/YUY2 optional, can drive 3840x2160 MJPEG 30fps/H.264 30fps. High speed USB 2.0 interface camera module, Low power consumption, small outline and thin profile for embedded application. UVC Compliant Plug&Play, Just connect the camera to PC computer, laptop, Android device or Raspberry Pi with the USB cable without extra drivers to be installed or with HDMI cable to motitor for display directly Adjustable Parameters: Brightness, Contrast, Saturation, Hue, Sharpness, Gamma, White Balance, Backlight Compensation, Exposure Widely works with most operating system,include Win XP/Vista/Win7/Win8 / Win10/ Win11etc. Linux with UVC (above linux-2.6.26). MAC-OS X 10.4.8 or above/Android 4.0 or above with UVC/Raspberry Pi. Applications: Come with a metal case and rotatable bracket, this tiny camera is highly recommended for monitoring Octoprint 3D Printer/laser cutter/router, video surveillance system, live streaming, record lesson and conference, lightburn camera for laser engraver, and other vision applications demand high resolution and high frame rate.
Sensor: 1/2.8” IMX415
Max Resolution: 3840(H)*2160(V)
Sensitivity: 0.65V/lux-sec@550nm
Pixel Size: 1.45µm x 1.45µm
Video Compression: MJPEG / YUY2(YUYV) / H.264

Resolution & Frame Rate:
3840x2160 MJPEG 30fps/ H.264 30fps/
2560x1440 MJPEG 30fps/ H.264 30fps/
1920x1080 MJPEG 30fps/ H.264 30fps/YUY25fps
1280x720 MJPEG 30fps/ H.264 30fps/ YUY2 10fps
1024x576 MJPEG 30fps/ H.264 30fps/YUY215fps
960x540 MJPEG 30fps/ H.264 30fps/ YUY2 15fps
640x480 MJPEG 30fps/ H.264 30fps/ YUY2 30fps
640x360 MJPEG 30fps/ H.264 30fps/ / YUY2 30fps

Image Processing Time: About 8 seconds after opening the preview software
Central Definition: 1000 LW/PH(Center)
S/N Ratio: 30 dB
Min illumination: 0.2 Lux
Shutter Type: Electronic Rolling Shutter/ Frame Exposure
Connecting Port Type: USB 2.0 Interface &HDMI V1.4 Interface
AEC Support
AWB Support
AGC Support
Adjustable Parameters:
Brightness, Contrast, Saturation, Hue, Sharpness, Gamma,White Balance,
Backlight Compensation, Exposure
Lens Parameter: 120degree low distortion lens, HFOV about 120-125degree.
Power Supply & Interface: USB Type-C Power Supply, Type-C & HDMI Display Simultaneous
Operating Voltage: DC 5V
Working Current: 480-500mA
Storage Temperature: -20°C to 80°C
Working Temperature: -10°C to 70°C
USB Cable 2 pieces cables:
(1PCS 1.2m cable with Type-C port, 1PCS 1.5m cable with HDMI port)

Operating System Request:
Win7/Win8/Win9/Win10/Win11 etc. Linux with UVC
MAC-OSX10.4.8 or later
Android 5.x or above
