Seetronic SAC3FCA Lockable 3-Pin Power-in Connector | 20A Indoor Powercon Plug for Stage Lighting, Sound Consoles, LED Panels, Power Amplifiers, Audio

Seetronic SAC3FCA Lockable 3-Pin Power-in Connector | 20A Indoor Powercon Plug for Stage Lighting, Sound Consoles, LED Panels, Power Amplifiers, Audio

[𝗛𝗶𝗴𝗵-𝗣𝗲𝗿𝗳𝗼𝗿𝗺𝗮𝗻𝗰𝗲 𝗟𝗼𝗰𝗸𝗮𝗯𝗹𝗲 𝗖𝗼𝗻𝗻𝗲𝗰𝘁𝗼𝗿]: The Seetronic SAC3FCA is a lockable 3-pin power-in connector designed for secure indoor AC power transfer in professional audio, lighting, and AV setups. Rated for 20A at 250V AC, it delivers a dependable connection for stage lighting, sound consoles, LED panels, power amplifiers, and audio racks. Compatible with SAC3MCA, SAC3MPA, and SAC3MPA-M, it offers a firm latch locking system to prevent accidental disconnection during critical live events and demanding applications. [𝗣𝗿𝗲𝗺𝗶𝘂𝗺 𝗕𝘂𝗶𝗹𝗱 & 𝗖𝗲𝗿𝘁𝗶𝗳𝗶𝗲𝗱 𝗦𝗮𝗳𝗲𝘁𝘆]: Built with a durable PA housing and copper alloy contacts plated with silver for enhanced conductivity, this connector ensures excellent performance over time. The SAC3FCA meets UL1977, IEC61984, IEC60320-1, and GB/T 34989 standards, carrying UL, VDE, TUV, and CQC certifications. Flame retardant to UL94-V0 and designed to withstand temperatures from -30°C to +80°C, it provides safe, stable power delivery in demanding professional environments. [𝗥𝗲𝗹𝗶𝗮𝗯𝗹𝗲 𝗘𝗹𝗲𝗰𝘁𝗿𝗶𝗰𝗮𝗹 𝗦𝗽𝗲𝗰𝗶𝗳𝗶𝗰𝗮𝘁𝗶𝗼𝗻𝘀]: Engineered for precision power transfer, the SAC3FCA features 3 contacts (line, neutral, PE) with a maximum contact resistance of just 5 mΩ. It supports a dielectric strength of 4000V DC and insulation resistance over 1000 MΩ, ensuring minimal loss and high reliability. These specifications make it ideal for audio/video installations, event production equipment, and professional lighting systems that require consistent, uninterrupted performance. [𝗟𝗼𝗻𝗴 𝗦𝗲𝗿𝘃𝗶𝗰𝗲 𝗟𝗶𝗳𝗲 & 𝗘𝗮𝘀𝘆 𝗜𝗻𝘀𝘁𝗮𝗹𝗹𝗮𝘁𝗶𝗼𝗻]: With a service life of over 1000 mating cycles, the SAC3FCA is built for repeated use in touring, studio, and stage environments. It accepts cables sized at 2.5 mm² (12 AWG) with an outer diameter of 8–12 mm and features screw-type terminals for secure wiring. Its quick locking mechanism allows fast setup and teardown, making it a trusted choice for AV technicians, stage crews, and rental companies seeking efficiency and reliability. [𝗩𝗲𝗿𝘀𝗮𝘁𝗶𝗹𝗲 𝗣𝗿𝗼𝗳𝗲𝘀𝘀𝗶𝗼𝗻𝗮𝗹 𝗔𝗽𝗽𝗹𝗶𝗰𝗮𝘁𝗶𝗼𝗻𝘀]:This blue connector is widely used in stage lighting rigs, LED display panels, audio racks, power amplifiers, and sound reinforcement systems. Its compatibility with popular PowerCon standards makes it a reliable alternative to Neutrik PowerCon connectors. Ideal for fixed installations or mobile setups, it offers secure, high-current power input for any professional AV, event production, or broadcast environment requiring dependable power connectivity. The SAC3 FCA Power Plug by Seetronic is a high-quality, lockable three-core power-in cable connector designed for reliable indoor use. This versatile connector is an ideal choice for applications requiring secure connections with contacts for line, neutral, and pre-adapted safety grounding. Lockable three-core power cable connector with contacts for line, neutral and pre-adapted safety grounding Non-waterproof, suitable for indoor use application Fast and easy locking system with firm latch lock which does not fall off High current capacity rated at 20A/250V AC UL Certification No. E359036 VDE Certification No. 40044166 Electrical Parameters: Number of Contacts: 2 + PE Rated Current: 20A Rated Voltage: 250V AC Contact Resistance: ≤ 5 mΩ Dielectric Strength: 4000V DC Insulation Resistance: > 1000MΩ Mechanical Parameters: Service Life: Exceeds 1000 mating cycles, ensuring long-term durability. Cable Size: Compatible with 2.5 mm² cables. Cable Outer Diameter: White strain relief: φ 8-11 mm, Black strain relief: φ 11-12 mm. Terminals: Equipped with screw type terminals for secure connections. Material and Environmental Parameters: Housing Material: PA (Polyamide) Contacts Material: Cu (Copper) alloy with Ag (Silver) surface for optimal conductivity. Flame Retardant Rating: UL94-V0 compliant, ensuring high safety standards. Temperature Range: Operates efficiently between -30°C and +80°C. Standards Compliance: Meets UL1977, IEC61984, IEC 60320-1, GB/T 34989 standards.
