JOYSOG Ebike Controller Kit, 36V 48V 52V 1500W E-Bike Control Module Support 3-Mode for E-Bike Part

JOYSOG Ebike Controller Kit, 36V 48V 52V 1500W E-Bike Control Module Support 3-Mode for E-Bike Part

Sine wave controller is is suitable for 48V 52V 1500W , Rated Power: 36V 650W/ 48V 860W/ 52V 930W; Peak Power: 36V 1200W/ 48V 1600W/ 52V 1800W. Support 3-mode: hall sensor mode/non-hall mode/self-learning, and smart match with each motor through self-learning, works with high efficiency, less noise, and lower energy consumption, which makes your comfortable and easier to control, give you best pedal experience. Work with hall sensor mode or non-hall mode, smart match with different motor, 5-speed level for throttle and PAS, Speed limit, Reverse, Cruise, Push Assistant, Anti-thief, Regenerative Braking, Braking and etc. Built-in multiple protection: over/under voltage, over current, over load, over heating, anti-runaway, locked-motor protection, ensure that can operate safely and stably in complex environments. There are 2 specifications for you to choose from: Only Controller/Controller + EN06 LCD Display(LCD display can clearly show the state and data)

Note: If you are not sure E-controller whether it is compatible, please contact us immediately.

Material: Aluminium

Universal Input Voltage Range: 36V/48V/52V

Rated Power: 36V 650W/ 48V 860W/ 52V 930W

Peak Power: 36V 1200W/ 48V 1600W/ 52V 1800W

Brake: Low Voltage Brake

Alarm: Low Voltage Alarm

Rotor Position Detecting Method: Hall sensor

Size: 212x86.5x48.5mm

Weight: 610g

Waterproof Grade: IP65

Why 3-mode Controller?

1. Support Hall Sensor Mode (Sine Wave Mode)

2. Support Non-Hall Mode (If your motor hall sensor burned or not match, controller will still work in square wave mode)

3.Self-learning Function: Even wrong 3-phase combination between motor and controller, doesn’t matter, above self-learning process can correct it!
