WayPonDEV Banana Pi BPI-WiFi 6 Router OpenWRT Board, Dual Band Wireless Internet Router, 802.11ax ac WiFi 6 Gigabit VPN Router, with 5GE Phy and RGMII

WayPonDEV Banana Pi BPI-WiFi 6 Router OpenWRT Board, Dual Band Wireless Internet Router, 802.11ax ac WiFi 6 Gigabit VPN Router, with 5GE Phy and RGMII

Banana Pi BPI-Wifi6 Mini Router design with Triductor TR6560 + TR5220 wifi SoC, built-in high-performance dual-core ARM Cortec A9 processor for WIFI message forwarding or intelligent business processing, built-in LSW and NAT hardware, supporting up to 5Gbps message forwarding. Banana Pi BPI Wifi6 Mini wireless Internet router support dual-band 2.4G 40M 2*2 +5G160M2.2 DBDC WIFI,Wifi protocol version support to IEEE 802.11ax, backward compatible 802.11a /b/g/n/ac, can support the highest rate of 3Gbps, 2G will reach 573.5Mbps, while 5G will reach 2401.9Mbps. Banana Pi BPI Wifi6 Mini OpenWRT router supports 6 GE MACs,1000M/100M/10M rate mode and standard MIB statistics. Support Wifi AP mode and STA mode. It can also support WPA,WPA2, WPA3 encryption and decryption, pay Chinese WAPI standard. Banana Pi BPI-Wifi6 Mini dual band router board integrated 5GE PHY, one RGMII,Supports one RGMII expansion port, provides 1000Mbps network access capability, and supports two WAN ports. It can also support hardware intelligent QoS. Banana Pi Wifi6 Mini Gigabit VPN Router don't onboard PoE interface , only BPI WIFI6 router adding PoE module to support PoE function. The PoE module port is reserved on the BPI WIFI 6 router board. If the PoE module is welded to the board, the PoE network cable power supply function is supported. [After-sales Service] Getting Start or SDK Document. All technical, after-sales and bulk orders questions, please leave the message to "wpd#youyeetoo&com (#--->@,&--->.)" or please click "WayPonDEV" store and ask the question.

-Specification-

Dual core ARM cortec A9 1.2G Hz

Integrated 5GE PHY, one RGMII

Supports 6 GE MACs,1000M/100M/10M rate mode and standard MIB statistics

Supports IEEE802.11a/b/g/n/ac/ax wireless LAN communication protocol

Support Wifi AP mode and STA mode

Support WPA,WPA2, WPA3 encryption and decryption, pay Chinese WAPI standard

PoE function support

-OS Support：OpenWRT

Dimensions: 92 mm x 62mm

Operating temperature: 0℃ ~ 80℃
