ELP 5MP 50fps Global Shutter USB Camera with Housing for Computer UVC USB2.0 Lightburn Camera for Laser Engraver High Speed 60fps PC Cam Wide Angle

ELP 5MP 50fps Global Shutter USB Camera with Housing for Computer UVC USB2.0 Lightburn Camera for Laser Engraver High Speed 60fps PC Cam Wide Angle

Ultra HD: still picture resolution: 2592x1944 Max. Global Shutter: all pixels in the image are exposed simultaneously, free of distortion, shooting high-speed moving objects in crisp sharp images. 1/2.5” OmniVision OX05B10 lightburn camera. Picture format MJPEG or YUY2 optional, cameras with high resolution can be used in any video system for personal or industrial. High Speed: 2592x1944@50fps MJPEG/2592x1440@60fps MJPEG, 2560x1440@60fps MJPEG/ 2304x1296@60fps MJPEG 2048x1536@50fps MJPEG, etc. M12 mount, 100degree no distortion Lens, wider angle of viewing range, HFOV: about 98degree, VFOV: about 84degree. The OmniVision OX05B10 sensor works with as little as 0.1 LUX. Super small and Mini Size for your lightburn laser engraver. Compact lightburn laser camera for all kinds of machine vision. Plug&Play: UVC-compliant, just connect the camera to PC computer, laptop, Android device or Raspberry Pi with the USB cable without extra drivers to be installed. USB webcam widely works with WinXP/Vista/Windows 7/8, Windows 10 Linux with UVC. Webcam for MAC, PC, desktop computer, laptop USB. Applications: this mini 38mmx38mm camera board can be installed in most hidden and narrow position for a home surveillance system, wildlife photography, dashcam, baby camera, gesture and eye tracking, iris and physiognomy recognition, depth and motion detection.etc.
Model ELP-USBGS5MP01-BH100
Sensor 1/2.5” OmniVision OX05B10 (Global Shutter)
Max Resolution (Default) 2592 (H) *1944 (V)
Sensor Size 1/2.5 inch (4:3)
Image Array Area 5737μm x 4312μm
Pixel Size 2.2μm x 2.2μm
Compression Format MJPEG / YUV2 (YUYV)
Resolution & Frame Rate:
2592x1944@50fps MJPEG/2592x1440@60fps MJPEG 2560x1440@60fps MJPEG
2304x1296@60fps MJPEG/2048x1536@50fps MJPEG/1920x1080@60fps MJPEG
1600x1200@50fps MJPEG/1600x900@60fps MJPEG/1280x960@50fps MJPEG
1280x720@60fps MJPEG/1024x768@50fps MJPEG/1024x576@60fps MJPEG
960x720@50fps MJPEG/960x540@60fps MJPEG 800x600@50fps MJPEG
800x450@60fps MJPEG 848x480@60fps MJPEG/640x480@50fps MJPEG 640x360@60fps MJPEG
Surface Mount: Technology SMT
Focus: Fixed Focus
Central Definition: 1000LW/PH (Center)
S/N Ratio: 38dB
Dynamic Range: 72dB
Sensitivity 1.4V/lux-sec@550nm
Min Illumination 0.1 Lux
Shutter: Global Shutter
Interface: USB2.0 High Speed
AEC/AWB/AGC Support
Adjustable Parameters: Brightness, Contrast, Saturation, Hue, Sharpness, Gamma, White
balance, Backlight Compensation, Exposure
Lens Parameters: 100degree no distortion lens
LED board power connector: Support 2P-2.0mm socket
Power Supply: USB BUS POWER 4P-2.0mm socket
Operating Voltage: DC 5V Working Current 180mA- 230mA
Working Temperature 0°C to 60°C
Storage Temperature -20°C to 80°C
USB Cable: 3M
Operating System Request:
WinXP/Vista/Win7/Win8/Win9/Win10/Win11 etc. Linux with UVC (above linux-2.6.26)
MAC-OS X 10.4.8 or later, Android.
