Upgrade Power Wheel Adapter Kit Compatible with Ryobi M18 18V Battery with Voltage Regulator Fuse and Wire Terminals, Battery Conversion Kit for DIY

Upgrade Power Wheel Adapter Kit Compatible with Ryobi M18 18V Battery with Voltage Regulator Fuse and Wire Terminals, Battery Conversion Kit for DIY

Multiple Protection: Battery adapter is equipped with a DC low voltage protector and 32A fuse to provide overcurrent protection and low voltage protection. When battery voltage reaches the set minimum value, it will automatically turn off the power to protect your equipment Waterproof Upgrade: Made of high-quality ABS material, upgrade battery conversion kit has stronger heat resistance and durability. The upgraded low-voltage protection controller has perfect waterproof and dustproof effect, avoiding damage to the exposed circuit board caused by rainwater and dust, effectively extending its service life Perfect Fit: The battery adapter kit is compatible with Ryobi 18V lithium-ion batteries P102 P103 P104 P105 P107 P108 P109 PBP002 PBP003 PBP004 PBP005 PBP006 P189 P190 P191 P192 P193 P194 P195 P197 BPL-1820G BPL-1815 BPL-18152, Widely used in DIY wireless control trucks, robots, and car toys Flexible Adjustment: The Battery adapter kit can easily adjust the voltage according to your own needs, and it is equipped with a voltage display for easy observation. DC motor controller is equipped with a speed and switch controller, and can display the output voltage in real time Easy to Install: You can directly insert a battery compatible with the product into the adapter, and then connect the adapter kit to your device to easily adjust the speed of your DIY Radio Controlled truck robot and car toy Note: Due to PCB size limitations, this low-voltage protection module uses a miniature relay and thin wire design. Therefore, in actual use, the current should not exceed 8A to avoid damaging the relay contacts. The low-voltage protection will still operate when the set voltage is reached; it is recommended to disconnect the power supply immediately The power wheel adapter kit is compatible with motor power sources such as toy cars and lithium battery power sources to obtain new motor power supply, achieving the goal of improving speed or range.
Instructions for Low Voltage Protection: Connect the lithium battery power supply to the inlet and set the minimum passing voltage through the module.

Attention: Please ensure that the positive and negative poles in the circuit are correctly connected and the adaptive wheel motor supports wide voltage.

Example settings:
Stop below 12.5V and start above 14V:
Set protection value: Press the "+" once to display the protection value. Long press the "+" and the decimal point will flash. Press the "+" to change the value to 12.5. If there is no operation for 3 seconds, the module will automatically save and exit the setting mode. Set hysteresis value: Press "-" once to display the hysteresis value. Long press "-" to make the decimal point blink. Press "+" or "-" to change the value to 1.5. If there is no operation for 3 seconds, the module will automatically save and exit the setting mode.

Restore factory settings:
When the power is disconnected, press and hold both buttons at the same time, and then turn on the power. At this time, the screen displays "888" to indicate that the factory settings have been successfully restored.

Package Includes：
1 pcs power wheel adapter
1 pcs fully waterproof adjustable DC low voltage protection
1 pcs DC PWM motor controller
1 pcs voltage display
2 pcs 30A fuse
1 pcs wiring terminal
