ZWO ASI585MC AIR Cooled Color Astronomy Camera w/Built-in Guide Camera & ASIAir with Power Supply

ZWO ASI585MC AIR Cooled Color Astronomy Camera w/Built-in Guide Camera & ASIAir with Power Supply

10 Unmissable Advantages:1.3 in 1 Camera: Imaging, Guiding, Control System 2.256G eMMC Storage 3.STARVIS 2 Technology 4.4K Resolution 5.Multiple Interface（Type-C x1 USB 2.0 x4 DC 12V 10A x2） 6.5G/2.4G Dual-band Wi-Fi / Bluetooth 7. Intelligent Live Stacking 8. High Signal-to-Noise Ratio, High Sensitivity 9. Voice Broadcast 10.Get Fully Control of Your Entire Rig at Your Fingertips With 256GB eMMC storage, the ASI585MC Air allows you to capture multiple targets with ease. Rigorously tested with over 300 benchmarks, it ensures system stability. Plus, the USB 2.0 ports support up to 1TB external storage, giving you plenty of room for all your astrophotography needs. Image Sensor Technology Beyond the Human Eye’s Sensitivity Equipped with the upgraded STARVIS 2 image sensor, supporting a higher dynamic range. With this technology, the sensitivity and signal-to-noise ratio of the ASI585MC Air are greatly enhanced, delivering exceptional image quality. The ASI585MC Air exhibits zero amp glow, which ensures extremely clean dark-field images. No matter how long the exposure and how the gain value, you can easily capture high-quality astrophotographs. 300s exposure image Note: It is implemented directly at the hardware level, it does not require software control. The ASI585MC Air incorporates multiple ZWO patented technologies and allows you to shoot simply by connecting your phone. It supports App OTA updates, continuously improving the product features, making astrophotography easy and fun, while enriching the user experience. The camera has a built-in HCG mode, which can effectively reduce readoutnoise at high gain and allow the camera to maintain the same high dynamicrange as it does at low gain. When the gain is 252, the HCG mode isautomatically turned on and the Dynamic range reaches a level close to 12bit.The readout noise is as low as 0.7e. ASI585MC Air can lower the CMOS sensor temperature to 30-35 degrees Celsius below ambient temperature, which can greatly reduce dark current generation and sensor noise even during extended exposure times. The ASI585MC Air combines three astrophotography accessories into one unit: a main imaging camera, a guide camera, and a smart controller. Aside from a telescope and mount, this camera contains everything a beginner imager needs to get started in astrophotography at an affordable price!
Main Imaging Camera
Sensor: IMX585
Sensor Type: Color
Sensor Size: 1/1.2''
Pixel Size: 2.9μm
Shutter: Rolling shutter
Image Resolution: 3840×2160
Spectrum Range: 200nm–1000nm
Read Noise: 0.7–6.67e (3.8e @ 19.8dB gain)
Peak Quantum Efficiency: < 91%
Full Well Capacity: 40Ke*
Diagonal: 13.2mm
SNR: 12 stops
Dynamic Range: 12 bit
Frame rates:
1920 × 1080 at 10.8fps
1280 X 960 at 17.2fps
1280 × 720 at 22.2fps
640 × 480 at 30fps
480 X 360 at 30fps
320 × 240 at 30fps
Guide Camera
Sensor Type: Mono
Sensor Size: 1/1.8''
Pixel Size: 4μm
Shutter: Rolling shutter
Image Resolution: 2.07MP (1920×1080)
Spectrum Range: 300nm–1000nm
Read Noise: 0.6–3.2e (1e @ 10.6dB gain)
Peak Quantum Efficiency: 92% at 500nm
Full Well Capacity: 8.78Ke
Diagonal: 8.81mm
Max Frame Rate: 8.5 fps (1920×1080)
SNR: 11.4 stops
Dynamic Range: 11.43 bit
Dimensions, Weight, & More
Camera body: 78mm diameter x 108mm long
Antenna: 94mm long
Weight: 1lb, 6oz (635g)
Operating Temperature: -20°C to 50°C
Storage Temperature: -20°C to 60°C
Operating Humidity: 20% ~ 90%
Storage Humidity: 30% ~ 70%
RAM: 2GB DDR4
Storage Space: eMMC 256GB
Wireless Network: IEEE 802.11a/b/g/n/ac, 2.4GHz/5GHz, effective range: 20m
DC Power: 12V @ 3A–10A input; all 3 DC ports can be used as input or output
HUB: USB 2.0 – HUB ×4
OS: Windows, Linux, Mac OS
Adapter Ring: M42×0.75
Back Focus: 12.5mm or 17.5mm
Power Mode: DC 12V – 3A (whole unit)
Max Power Dissipation: 24.6W (whole unit)
