uxcell KSD301 Thermostat 5°C/41°F 10A Normally Open N.O Adjust Snap Disc Temperature Switch 8pcs,Bakelite Material

uxcell KSD301 Thermostat 5°C/41°F 10A Normally Open N.O Adjust Snap Disc Temperature Switch 8pcs,Bakelite Material

Type: KSD301 5 degrees Celsius Thermal Control Switch 110V/120V/250V 10A NO (Normal Open) Normally Open: The original state of temperature control switch contact is open, and closed when the temperature sensing exceeds the rated temperature 5 Celsius degree Advantage: Double metal chip, speed dynamic type, sensitive, reliable, stable action temperature, long service life, no arc phenomenon. Easy to installation : The flange on the switch is float and easy to installation.The pin width is 6.3mm Application: Mainly used for microwave,oven,coffee maker,Speed Cook oven,heater,Dryer,gas furnace,Bath Vent/Heater,wall heater,motor electric heating water dispenser, water bottles, coffee shell, electric iron, dryer, air conditioning, water heater, electronic cooker, heater, motor cleaner Specification:
Product Name : Temperature Control Switch
Model: KSD301
Action Temperature: 5°C
Action Type: N.O (Normally Open)
Rated Voltage/Current : 110V/120V/250V 10A
Pin Width : 6.3mm/0.25inch
Contact Life: More than 50,000 times (action times)
Electrical Strength: AC50Hz, 2000V/min no breakdown and arc phenomenon

Package Content :
8pcs x Temperature Control Switch

Description :
1.Normally Open: The original state of temperature control switch contact is open, and closed when the temperature sensing exceeds the rated temperature.
2.Feature: Double metal chip, speed dynamic type, sensitive, reliable, stable action temperature, long service life, no arc phenomenon.
3.Advantage: General purpose, automatic reset, low cost, large capacity, minute current thermostats.
4.Application: Mainly used for microwave,oven,coffee maker,Speed Cook oven,heater,Dryer,gas furnace,Bath Vent/Heater,wall heater,motor electric heating water dispenser, water bottles, coffee shell, electric iron, dryer, air conditioning, water heater, electronic cooker, heater, motor cleaner
